LOWRANCE Eagle 7 Fish Finder - TRIPLESHOT™ HD TRANSDUCER AND C-MAP DISCOVER™ ONBOARD
Original price
$939.00
-
Original price
$939.00
Original price
$939.00
$939.00
-
$939.00
Current price
$939.00
Eagle® was born to make fishing as simple and enjoyable as possible. Easy to use and quick to install, this model features newly designed TripleShot™ HD Transducer with FishReveal technology and autotuning for a quick and optimal set up. A new IPS screen provides higher resolution and visibility from all angles. This model comes pre-loaded with a worldwide basemap chart, and the option to upgrade to CMAP® DISCOVER™.
Specifications:
Display
Backlight Color - Pure White LED
Display Resolution - 800x480
Screen Brightness - 1000 Nits
Viewing Angles - 80° top/bottom, 80° left/right
Connectivity
SD Card Storage - 1 slot (microSD® 32 GB maximum)
Cartography
Charts supported - C-MAP® DISCOVER™
Electrical
Power Consumption max - 550 mA @ 12 V DC with backlight on full
Power Consumption min - 250 mA @ 12 V DC with backlight off
Power Consumption typical - 550 mA @ 12 V DC with backlight on full
Recommended Fuse Rating - 3A
Supply Voltage - 12 v DC (10.8-17VDC)
Environment
Humidity - 60°C, 95% relative humidity (RH) for 48 hours
Operating Temperature Range - 5°F to 131°F (-15°C to 55°C )
Storage Temperature Range - 4°F to 140°F (-20°C to 60°C )
Waterproof rating - IPX7 with card door closed
GPS
Correction - SBAS
Time to First Fix - 45s
MFD
Cartography included - C-MAP® Discover OnBoard™ charts for the US and Canada
Waypoints, Routes, Tracks - 3000 Waypoints 100 Routes 100 Trails
Physical
Compass Safe - 12" (300mm)
Dimensions W x H x D - 8.89" (225.9mm) x 5.5" (139.8mm) x 3.48" (88.5mm)
Mounting Type - Gimbal bracket or dash mount
Weight - 1.48lb (0.67kg)
Other
Interface - Keypad:8-way directional keypad, Zoom +/- (MOB), Exit, Enter, Menu, Waypoint, Power / backlight
Warranty Period - 1 Year + 4 additional years of upgrade options totaling 5 years
